RESILIENT SOUNDS PLATINUM V2 18" DUAL 1 OHM (D1) SUBWOOFER
The Pinnacle of Competition-Grade Low-Frequency Output
The Resilient Sounds PLATINUM V2 18" D1 is purpose-built for the most extreme and competitive audio systems, delivering maximum output at ultra-low impedance. This flagship 18-inch subwoofer maintains a conservative 2,500W RMS rating, utilizing a 13% larger motor and a 20% longer 3-inch 8-layer voice coil to provide unmatched force and thermal stability. The Dual 1 Ohm impedance is the definitive configuration for maximizing amplifier power, allowing for an incredibly low 0.5 Ohm final load when wired in parallel. With a colossal 35mm XMAX, the Platinum V2 18" pushes the boundaries of low-frequency reproduction with authority, speed, and precision.
TECHNICAL SPECIFICATIONS
| Specification | Detail |
| Model | Platinum 18 V2 |
| Nominal Impedance | Dual 1 Ohm (D1) |
| RMS Power Handling (Conservative) | 2,500 Watts |
| Peak Power Handling | 5,000 Watts |
| Maximum Excursion (XMAX) | 35MM |
| Voice Coil | 3-inch 8 Layer (20% Longer than V1) |
| Motor Structure | 13% Larger Motor, XL Triple Stacked |
| Cone / Dust Cap | Carbon Fiber |
| Surround | New High Roll Tooled Surround |
| Spider / Leads | 10" Spider Pack with Insulated Dual Leads |
| Frame/Basket | Cast Aluminum Frame |
RECOMMENDED ENCLOSURE SPECIFICATIONS
| Internal Volume (Cubic Ft) | 4 - 6 CU FT |
| Tuning Frequency | 28 - 33 HERTZ |
| Port Area | 12 - 16 SQ INCHES OF PORT AREA PER CUBIC FT |
| Mounting Depth | 12.5 INCHES |
| Cutout Diameter | 16.93 INCHES |
| Displacement | 0.33 CUBIC FT |
Description
The Pinnacle of Competition-Grade Low-Frequency Output
The Resilient Sounds PLATINUM V2 18" D1 is purpose-built for the most extreme and competitive audio systems, delivering maximum output at ultra-low impedance. This flagship 18-inch subwoofer maintains a conservative 2,500W RMS rating, utilizing a 13% larger motor and a 20% longer 3-inch 8-layer voice coil to provide unmatched force and thermal stability. The Dual 1 Ohm impedance is the definitive configuration for maximizing amplifier power, allowing for an incredibly low 0.5 Ohm final load when wired in parallel. With a colossal 35mm XMAX, the Platinum V2 18" pushes the boundaries of low-frequency reproduction with authority, speed, and precision.
TECHNICAL SPECIFICATIONS
| Specification | Detail |
| Model | Platinum 18 V2 |
| Nominal Impedance | Dual 1 Ohm (D1) |
| RMS Power Handling (Conservative) | 2,500 Watts |
| Peak Power Handling | 5,000 Watts |
| Maximum Excursion (XMAX) | 35MM |
| Voice Coil | 3-inch 8 Layer (20% Longer than V1) |
| Motor Structure | 13% Larger Motor, XL Triple Stacked |
| Cone / Dust Cap | Carbon Fiber |
| Surround | New High Roll Tooled Surround |
| Spider / Leads | 10" Spider Pack with Insulated Dual Leads |
| Frame/Basket | Cast Aluminum Frame |
RECOMMENDED ENCLOSURE SPECIFICATIONS
| Internal Volume (Cubic Ft) | 4 - 6 CU FT |
| Tuning Frequency | 28 - 33 HERTZ |
| Port Area | 12 - 16 SQ INCHES OF PORT AREA PER CUBIC FT |
| Mounting Depth | 12.5 INCHES |
| Cutout Diameter | 16.93 INCHES |
| Displacement | 0.33 CUBIC FT |
