RESILIENT SOUNDS PLATINUM V2 15" DUAL 1 OHM (D1) SUBWOOFER
The Ultimate Low-Impedance Subwoofer for Extreme Systems
The Resilient Sounds PLATINUM V2 15" D1 is the choice for serious bass enthusiasts and competitors seeking to run ultra-low impedance loads. Built to handle a conservative 2,500W RMS, this 15-inch driver is optimized for maximum thermal and magnetic performance with its 13% larger motor and 20% longer 3-inch 8-layer voice coil. The Dual 1 Ohm impedance allows for wiring in parallel to achieve an extremely low 0.5 Ohm final load, unlocking the full potential of 0.5 Ohm-stable competition-grade amplifiers. The combination of 35mm XMAX, carbon fiber cone, and heavy-duty suspension ensures this subwoofer moves huge amounts of air with unmatched authority and control.
TECHNICAL SPECIFICATIONS
| Specification | Detail |
| Model | Platinum 15 V2 |
| Nominal Impedance | Dual 1 Ohm (D1) |
| RMS Power Handling (Conservative) | 2,500 Watts |
| Peak Power Handling | 5,000 Watts |
| Maximum Excursion (XMAX) | 35MM |
| Voice Coil | 3-inch 8 Layer (20% Longer than V1) |
| Motor Structure | 13% Larger Motor, XL Triple Stacked |
| Cone / Dust Cap | Carbon Fiber |
| Surround | New High Roll Tooled Surround |
| Spider / Leads | 10" Spider Pack with Insulated Dual Leads |
| Frame/Basket | Cast Aluminum Frame |
RECOMMENDED ENCLOSURE SPECIFICATIONS
| Internal Volume (Cubic Ft) | 2.5 - 3.5 CU FT |
| Tuning Frequency | 28 - 33 HERTZ |
| Port Area | 12 - 16 SQ INCHES OF PORT AREA PER CUBIC FT |
| Mounting Depth | 11.25 INCHES |
| Cutout Diameter | 14.2363 INCHES |
| Displacement | 0.28 CUBIC FT |
Description
The Ultimate Low-Impedance Subwoofer for Extreme Systems
The Resilient Sounds PLATINUM V2 15" D1 is the choice for serious bass enthusiasts and competitors seeking to run ultra-low impedance loads. Built to handle a conservative 2,500W RMS, this 15-inch driver is optimized for maximum thermal and magnetic performance with its 13% larger motor and 20% longer 3-inch 8-layer voice coil. The Dual 1 Ohm impedance allows for wiring in parallel to achieve an extremely low 0.5 Ohm final load, unlocking the full potential of 0.5 Ohm-stable competition-grade amplifiers. The combination of 35mm XMAX, carbon fiber cone, and heavy-duty suspension ensures this subwoofer moves huge amounts of air with unmatched authority and control.
TECHNICAL SPECIFICATIONS
| Specification | Detail |
| Model | Platinum 15 V2 |
| Nominal Impedance | Dual 1 Ohm (D1) |
| RMS Power Handling (Conservative) | 2,500 Watts |
| Peak Power Handling | 5,000 Watts |
| Maximum Excursion (XMAX) | 35MM |
| Voice Coil | 3-inch 8 Layer (20% Longer than V1) |
| Motor Structure | 13% Larger Motor, XL Triple Stacked |
| Cone / Dust Cap | Carbon Fiber |
| Surround | New High Roll Tooled Surround |
| Spider / Leads | 10" Spider Pack with Insulated Dual Leads |
| Frame/Basket | Cast Aluminum Frame |
RECOMMENDED ENCLOSURE SPECIFICATIONS
| Internal Volume (Cubic Ft) | 2.5 - 3.5 CU FT |
| Tuning Frequency | 28 - 33 HERTZ |
| Port Area | 12 - 16 SQ INCHES OF PORT AREA PER CUBIC FT |
| Mounting Depth | 11.25 INCHES |
| Cutout Diameter | 14.2363 INCHES |
| Displacement | 0.28 CUBIC FT |
